特性项目 | 规格 | 单位 | |||||||
Rated voltage | 12 | 24 | VDC | ||||||
frequency | 50/60 | HZ | |||||||
Turn to | CW, CCW, free rotation | ||||||||
Rotating speed | 2.5/3 | 3.3/4 | 4.2/5 | 5/6 | 8.3/10 | 10/12 | 20/24 | 30/36 | R.P.M |
Braking torque | 6 | 5 | 4 | 3 | 1.5 | 1.0 | 0.8 | 0.5 | kgf-cm |
Slip torque | 7~10 | kgf-cm | |||||||
Number of poles | 8 | Pole | |||||||
power | 3.8 / 4.0 | W | |||||||
Withstand voltage standard | AC 1500V-1min Detection current 10mA | ||||||||
Insulation class | E | Class |
项次 | 规格 | 出綫长度 | 裸綫 |
1 | AWG 1007#22 | 200mm | 10:10 Kathy |
2 | AWG 1007#22 | 450mm | 10:10 Kathy |
3 | AWG 1007#22 | 700mm | 10:10 Kathy |
4 | AWG 1015#22 | 200mm | 10:10 Kathy |
5 | AWG 1015#22 | 450mm | 10:10 Kathy |
6 | AWG 1015#22 | 700mm | 10:10 Kathy |
特性项目 | 规格 | 单位 | |||||||
Rated voltage | 12 | 24 | VDC | ||||||
frequency | 50/60 | HZ | |||||||
Turn to | CW, CCW, free rotation | ||||||||
Rotating speed | 2.5/3 | 3.3/4 | 4.2/5 | 5/6 | 8.3/10 | 10/12 | 20/24 | 30/36 | R.P.M |
Braking torque | 6 | 5 | 4 | 3 | 1.5 | 1.0 | 0.8 | 0.5 | kgf-cm |
Slip torque | 7~10 | kgf-cm | |||||||
Number of poles | 8 | Pole | |||||||
power | 3.8 / 4.0 | W | |||||||
Withstand voltage standard | AC 1500V-1min Detection current 10mA | ||||||||
Insulation class | E | Class |
项次 | 规格 | 出綫长度 | 裸綫 |
1 | AWG 1007#22 | 200mm | 10:10 Kathy |
2 | AWG 1007#22 | 450mm | 10:10 Kathy |
3 | AWG 1007#22 | 700mm | 10:10 Kathy |
4 | AWG 1015#22 | 200mm | 10:10 Kathy |
5 | AWG 1015#22 | 450mm | 10:10 Kathy |
6 | AWG 1015#22 | 700mm | 10:10 Kathy |
